44
Performance/Part Value Comment
Rope Personnel Lifting – EN 1891 A
11 mm (7/16”), Equipment
Lifting — SKYLOTEC ELR
See our website for tested ropes.
Polyamid ropes should be soaked before rst use.
See section 2.1
Safe Working Load
(SWL /WLL)
200 kg (440 lb)
Ascent speed 0-24 m/min (0-78 ft/min)
Descent speed 0-25 m/min (0-82 ft/min)
Emergency descent speed 0-25 m/min (0-82 ft/min)
Battery range Approximately 200 m at 100 kg
(656 ft at 220 lb)
At 20°C (68°F), continuous ascending. See section 4.2
Charging time 90 min Charging time for an empty Battery
Temperature range -10°C (14°F) to 40°C (104°F) Values apply to ambient temperature. See E.02 for more info
Over heating protection Yes
Ascender weight 10.5 kg (23,15 lb) Ascender weight with Battery is 13 kg (28,7 lb)
Battery weight 2.5 kg (5.5 lb)
