SPECIFICATION
Frequency Response: ...................................................... 40Hz-20kHz ± 3dB
Input Sound Source: ...................................................................... Line Input
Speaker: ................................. 8 inch Woofer & 2x Piezo Tweeter (178.438)
.............................................. 10 inch Woofer & 2x Piezo Tweeter (178.440)
.............................................. 12 inch Woofer & 2x Piezo Tweeter (178.442)
........................................ 2x 6.5 inch Woofer & 2x Piezo Tweeter (178.444)
........................................... 2x 8 inch Woofer & 2x Piezo Tweeter (178.446)
......................................... 2x 10 inch Woofer & 2x Piezo Tweeter (178.448)
Car reader memory medium: ......................................... MMC Card, SD Card
Power supply: ..................................................................... 230VAC at 50Hz
PANELS:
1. Microphone Input Sockets
2. Microphone volume control
3. Echo control
4. Bass control
5. Treble control
6. Master Volume control
7. MP3 Play/Pause/Track buttons
8. Speaker output
9. Line input
10. Power switch
11. AC power cable
OPERATION:
Connect the passive speaker with a good quality speaker cable to the speaker output connector
(21). WARNING: only connected the original slave speaker on the speaker output terminal!
If required connect an external signal source like a CD-layer to LINE IN.
Connect the device with an electric outlet (230VAC / 50Hz)
It is possible to connect an external antenna to the antenna socket for optimum radio reception.
