1.
Locate the Top tube with T-joint(1) and the Top tube
with Socket(2) as shown.
NOTE:
Make sure all the spring holes are facing ground.
Horizontal square tube
(used to connect the Top tube)
Vertical round tube
(used to connect the Leg extension)
T-joint
Horizontal square tube
(used to connect the Top tube)
Vertical round tube
(used to connect the Leg extension)
Vertical square tube
(used to connect Enclosure pole)
Socket
If you don’t assemble in the right order, you will have to
disassemble the entire trampoline in order to attach correctly.
NOTE:
Identify the T-joint and Socket shown in right will
be helpful for you, they are pre-installed on Top tube.
