Enclosure door
V-ring
Frame
5
8
5.3
5.4
T-joint
19
Attach the Spring as follows:
A: Hook one end of Spring into the V-ring sewn on Jumping
mat.
B: Hook a Spring Tool as shown to the free end of the Spring.
C: Pull the Spring until it reaches the frame.
D: Push the end of the Spring into a hole in the frame, then
unhookthe Spring Tool
CAUTION:
It is wise to wear leather gloves while attaching the springs.
Be careful where you place your hands as the Springs and
Frame joints can pinch.
NOTE: The smaller hook end should be placed within the
V-ring.
Attach another two lateral V-rings to frame holes in the
same way as 5.2
NOTE:
Count exactly the quantity of V-rings and the spring holes
on frame top, make sure each of them are corresponding.
NOTE:
There are 72 springs around the edge of Jumping mat(5)
and 72 holes around the top tube
Attach other V-rings to frame holes on left side of
T-joint or Socket in the same way as 5.2
Now there are12 V-rings attached to the Top tube. And 12
Springs have been used.
