16
5. Attach the Springs as follows:
Hook one end of a Spring into a V-ring. (See the inset
drawing.) Hook the Spring tool to the free end of the first
Spring. Using the Spring Tool pull the first Spring until it
reaches the frame. Push the end of the first Spring into a
hole in the frame. Unhook the Spring Tool.
Attach 2 silver color springs to each corner of the mat.
There should now be a total of 8 springs attached. Place
the middle springs (Gold Colored) next. To place the
middle springs count in 11 spaces from corner and attach
one middle spring. Do this on each side. The other middle
gold color springs go on each side of the center spring.
Note: Make sure the small opening of gold color
spring hook is attached to the V-Ring.
To place the remaining springs count exactly 5 V-rings
and 5 frame holes in a clockwise direction from one of
the corners. Repeat this on all sides. Attach remaining
Springs (not shown) evenly between the attached Springs
until all springs are attached.
Safety Note: For the Bed (Mat) (7) to have the even ten-
sion necessary for safety in jumping, the Springs must be
attached as described. As you attach Springs, carefully
count the V-rings and frame holes. If a V-ring or hole is
skipped, reattach the Springs in the proper position.
6. Lay one of the two frame Pad (10) on the frame.
Adjust the position of the Frame Pad so that the slits are
directly above the frames (2), as shown. Securely tie the
two frame pads together using the attached straps.
Inset drawing
Spring Tool Provided
Gold Color
Springs
Gold Color
Springs
Gold Color
Springs
Gold Color
Springs
To Next Page
