SLAT AES - General Information; Environmental Specifications; Electrical Input and Output Specifications

24
1 General information
1.1 Correspondence table
50 W 75 W 100 W 150 W 200 W 300 W 400 W 600 W
24 V 2 A 3 A 4 A 6 A 8 A 12 A 16 A 24 A
48 V 2 A 3 A 4 A 6 A 8 A 12 A
The currents (In) shown are at rated output power.
1.2 Environmental specifications
Operating temperature:
-5 °C to +40 °C at 100 % charge.
-5 °C to +50 °C at 75 % charge.
-5 °C to +50 °C at 100 % charge for 50 W to 100 W.
Storage temperature: -25 to +85 °C.
Relative humidity: 20 to 95 %.
Heat capacity consult our website:
www.slat.com
Environment class: 1 (according to EN 12101-10)
1.3 Electrical input and output specifications
1.3.1 Network input
- single-phase voltage: 195 V to 264 V.
- frequency: 50 to 60 Hz.
- class I.
- neutral systems: TT, TN, IT.
50
W
75
W
100
W
150
W
200
W
300
W
400
W
600
W
Primar
y
current
@
195 V 0.4 A 0.5 A 0.75 A 1 A 1.5 A 2 A 3 A 4 A
Circuit breaker to be provided upstream: D curve
1.3.2 Output
Rated volta
g
e 24
V
48
V
Floating voltage set at half-load and at 25 °C. 27.2 V ±0.5 % 54.4 V ±0.5 %
Max. output voltage. 28,58 V 57,16 V
Min. output voltage 20,95 V 41,90 V
The AES version can function without load current Imin = 0
The output current In max. can be used on a
single outlet or distributed among all outlets.
In
Maximum specified output current that can be
supplied continuously. (C=battery capacity).
I max a = In –C/20
Maximum specified output current greater than I
max a, that can be supplied for a short period of
time during which battery charging is not required.
I max b = In
Switching time 0s
