Slendertone ABS3 - Controller Symbols and Program Data; Explanation of Controller Symbols; Detailed Program Parameters

14
Program
Parameters
• Output Current
• Pulse Rate
• Pulse Duration (Width)
• Mode # 1
• Mode # 2
• Mode # 3
• Mode # 4
• Mode # 5
• Mode # 6
• Mode # 7
• Timer
• Compliance
• Waveform
• Maximum Charge Per Pulse
• Power Source
• Tolerances
0-70 milliamps, adjustable (up to 1K ohms load)
45, 50, 60, 70 and 75 pulses per second (PPS)
Positive pulse width 200 microseconds / Negative pulse width 200 microseconds /
Inter-phase interval 140 microseconds
Pulse rate 70 PPS / On time = 2.5 seconds / Off time = 2.5 seconds
Ramp Up and Down = 2 seconds / Timer = 20 minutes
Pulse rate 60 PPS / On time = 3.5 seconds / Off time = 3.5 seconds
Ramp Up and Down = 2 seconds / Timer = 25 minutes
Pulse rate 50 PPS / On time = 4.5 seconds / Off time = 4.5 seconds
Ramp Up and Down = 2 seconds / Timer = 30 minutes
Pulse rate 50 PPS / On time = 5.5 seconds / Off time = 5.5 seconds
Ramp Up and Down = 2 seconds / Timer = 40 minutes
Pulse rate 75 PPS / On time = 6.5 seconds / Off time = 6.5 seconds
Ramp Up and Down = 2 seconds / Timer = 30 minutes
Pulse rate 70 PPS / On time = 10 seconds / Off time = 10 seconds
Ramp Up and Down = 4 seconds / Timer = 30 minutes
Pulse rate 45 PPS / On time = 10 seconds / Off time = 10 seconds
Ramp Up and Down = 4 seconds / Timer = 30 minutes
20, 25, 30 and 40 minutes depending on the mode.
Complies with IEC 60601-1
Symmetrical biphasic with zero net DC
15 microcoulombs under normal conditions
3 x 1.5V AAA Batteries
All electrical specifications are ± 10% into real 500-ohm load
Description of your controller’s symbols:
There are a number of technical markings on your controller. These can be
explained as follows:
Inside the battery compartment ‘+’ indicates positive polarity and ‘-’ in-
dicates negative polarity. The batteries should be positioned as indicated by
three embossed outlines in the base of the compartment.
The controller and belt are made in China for Bio-Medical Research Ltd.,
Parkmore Business Park West, Galway, Ireland.
The controller requires three 1.5 volt DC batteries. DC is indicated by the
symbol:
This symbol means “Attention, consult the accompanying
documents”.
This symbol means type BF equipment (GelPads).
SN stands for ‘serial number’. On the label, on the back of the controller is the
serial number specific to this product. The letter preceding the number indicates
the year of manufacture, where ‘V’ denotes 2016, ‘W’ denotes 2017 etc.
The batch number of the belt is represented on the belt packaging,
by the number corresponding with the LOT symbol.
!
