Network → Network → DHCP enable – IP address receiving type (dynamic if this option enabled)
→ IP address – device IP address
→ Subnet mask – network subnet mask
→ Gateway – gateway IP address
→ Primary DNS – primary DNS server IP address
→ Secondary DNS – secondary DNS server IP address
→ TCP port – port number for data exchange between monitor and PC
→ Mobile port – mobile devices port number
→ Transfer policy – transfer policy type (adaptive, quality or uency preferred)
→ MTU – MTU port number
→ HTTP port – management port number
→ Net service → IP FILTER – IP addresses list for ltering
→ DDNS – DDNS server setup
→ UPNP – UPnP settings
→ Wi-Fi – Wi-Fi connection settings (additional info on the page 18)
→ RTSP – RTSP port number
Record → Record - record time schedule setting (additional info on the page 18)
→ Backup - creating backup archive (additional info on the page 19)
Alarm set → Motion detect → Channel – current channel number for making settings
→ Sensitivity – software motion detection sensitivity
→ Record channel – choose the channel number to perform recording
→ Push – enable/disable push messages while software motion detection
→ Enable – enable/disable software motion detection for current channel
→ Region – motion detection area setting (additional info on the page 20)
→ I/O alarm → Alarm input – current channel number for making settings
→ Type – type of hardware sensor (normally opened or normally closed)
→ Record channel – choose the channel number to perform recording
→ Push – enable/disable push messages for hardware motion detection
→ Enable – enable/disable hardware motion detection for current channel
Door setting → Basic → Call REC – incoming call recording mode: Video or Picture.
→ Do not disturb mode – turn o incoming calls melody (if enabled)
→ DND mode schedule – do not disturb mode enabling schedule
→ Ring → Door 1 ringtone – incoming call melody for the rst outdoor panel
→ Door 2 ringtone – incoming call melody for the second outdoor panel
→ Volume – incoming call melody volume
→ Ring time – incoming call melody ringing time
→ Door 1 unlock time – relay unlocking time for the rst outdoor panel
→ Door 2 unlock time – relay unlocking time for the second outdoor panel
→ Button sound – enable/disable touch sounds
Note:
* Monitor supports high resolution AHD, TVI and CVI outdoor panels and cameras with actual resolution
up to 1080p (2MP). Also two IP cameras can be connected to the Camera 1 and Camera 2 monitor
channels. If camera or outdoor panel video standard doesn’t suits monitor settings then there is no image
on the corresponding video channel.
Main menu has following structure:
System → General → System time – current date and time
→ Date format – date displaying format
→ Time format – time displaying format
→ Language – monitor menu language
→ SD full – enable overwriting data or stop record if SD card is full
→ Video standard – video signal type (PAL or NTSC)
→ CVBS out – additiaonal monitors video stadard: HD(AHD) or D1(CVBS)
→ Screensaver – enable/disable clock display in standby mode
→ Video → GUI display – video input name setting and additional indicators displaying
→ Image Set – video channel parameters settings (brightnes, contrast, saturation, etc.)
→ Output adjust – top, bottom, left and right margins adjust
→ Encode – compression modes for every single channel
→ Channel type – channel display mode (analog or digital)
