4 I/O Box SMA Solar Technology AG / SMA Solar Technology America LLC
10 IMVIOBOX-IA-xx-12 Installation Manual
4 I/O Box
4.1 Scope of Delivery
Check the scope of delivery of each product for
completeness and any externally visible damage.
Contact your distributor if the scope of delivery is
incomplete or damaged.
The delivery may contain parts that are not required for the
installation.
Figure2: Components included in scope of delivery of the I/O Box
4.2 Mounting the I/O Box
4.2.1 Option 1: Wall Mounting
4.2.2 Option 2: Mounting on
Top-Hat Rail
4.3 Connection to the I/O Box
4.3.1 Overview
Position Quantity Designation
A1 I/O Box
B1 CD
C 1 Quick reference guide for
installation
Damage to the products and cables due to moisture
The Inverter Manager and the I/O Box are not protected
against splash water. Consequently, moisture can
penetrate the device and damage the products and
cables.
• The Inverter Manager and the I/O Box must be
installed in a dry environment, e.g. indoors or in a
splash-proof enclosure (degree of protection: at least
IP54 (NEMA 3R)).
A
B
C
Position Designation
A Digital inputs for connecting a signal source
(inputs DI0 to DI5 can be assigned;
all other inputs have no function)
1
2
1
2
3
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
D1+
D1-
GND
D2+
D2-
P1
P2
V+
V-
X10
X1
Dual
Run
Rep
Initial
COM0
DI0
DI1
DI2
DI3
DI4
DI5
DI6
DI7
COM1
DIO0
DIO1
DIO2
DIO3
GND
DIO4
DIO5
DIO6
DIO7
GND
A
C
D
COM0
DI0
DI1
DI2
DI3
DI4
DI5
GND
B
E
