Shenzhen Smart Device Technology Co.,Ltd
Web: www.smdt.com.cn Tel: 0755-61662980 Fax: 0755-26992201
◆ BAT1 RTC Battery Port
Standard 2032 port,used to install the clock battery,supply power to the system clock when power
outages.
NO. Definition Property Description
1 RTC input 3V input
2 GND ground
electrode
ground electrode
◆ MIC Port
Please note that the MIC is positive negative connection,not reverse.
NO. Definition Property Description
1 MIC- input MIC-
2 MIC+ input MIC+
Speaker
