◆ Port Of Receiving Remote Control
NO. Definition Property Description
1 IR input remote control signal input
2 GND ground
electrode
ground electrode
3 3V3 Power 3.3V output
◆ Work Indicating Lamps
The default support gongyang red blue double LED lights.
NO. Definition Property Description
1 LED_B Blue light Work light
2 VCC Power supply 3.3V output
3 LED_R Red light Standby lamp
