Performance Specifcation Parameter
Equipment Model SDM300
MIC Input Sensitivity(MIC1/MIC2/MIC/MIC4) 600 ohms(Ω) 5mV, Balanced
Line Input (AUX) 10k ohms(Ω) 300mV, Un-balanced
Audio Signal Output (MAIN OUTPUTS) 10k ohms(Ω) 0.775V (0 dB), Balanced(L/R)
Monitor Signal Output（HEADPHONE)
10k ohms(Ω) 0.775V (0 dB), Un-balanced
Frequency Response 50Hz~18kHz(±3dB)
Nonlinear Distortion THD <0.05% at 1kHz
Signal-to-Noise Ratio(S/N) >70 dB
Tone Adjustment Range BASS:100Hz(±10dB) , TREBLE:10kHz(±10dB)
Power Input
AC110V-AC240V
，
50-60Hz
Power Consumption 30W
Net Weight (kg）
2.4
Product size(cm) 51*26*8.5
8
