CHECK BATTERY - AR54.10-P-1129-01A
Risk of explosion caused by oxyhydrogen gas. Risk of poisoning and caustic burns caused by swallowing
battery acid.
Risk of injury caused by burns to skin and eyes from battery acid or when handling damaged
lead-acid batteries
No fire, sparks, open flames or smoking. Wear acid-resistant gloves, clothing and glasses. Only pour
battery acid into suitable and appropriately marked containers.
TEST AND ADJUSTMENT VALUES FOR THE BATTERY
consumer or control unit is
removed, the no-load current
drops immediately.
The fuse and relay assignment
enables the increased no-load
current consumption to be
restricted to specific control
units and consumers.
To restrict the increased no-
load current consumption yet
further, the consumers and
control units protected by the
fuse in question must be
removed one after the other.
* not for USA
Fuse and relay box, as-built
configuration
GF54.15-P-0800MCC
* for USA only
Fuse and relay box, as-built
configuration
GF54.15-P-0800MCU
15 Remove multimeter without
breaking the circuit and attach
ground line (1) to negative
terminal
Install
16 Install foot support on
passenger side
Left-hand drive vehicles AR68.30-P-1340MCC
Right-hand drive vehicles AR68.30-P-1340MCE
17 Open vehicle using central
locking system
18 Unlock rotary tumblers on
doors and liftgate
19 Connect STAR DIAGNOSIS
then read-out and erase
diagnostic trouble code
memory
AD00.00-P-2000-
04MCC
Number Designation 12 AH 30 AH 35 Ah 46 AH
BE54.10-P-1002-
01A
Cold test current as per EN A 170 540 520 420
