Fig. 21: Identifying Battery Components
Courtesy of MERCEDES-BENZ OF NORTH AMERICA.
REMOVE/INSTALL ELECTRICAL LINE FROM BATTERY TO STARTER/ALTERNATOR -
AR54.18
-P-0006MCU
MODEL 451.3/4 (except 451.391 /491)
Fig. 22: Identifying Electrical Line Components
Courtesy of MERCEDES
-BENZ OF NORTH AMERICA.
Remove/install
1 Disconnect battery ground line AR54.10-P-0003MCC
2 Take off cover (1)
3 Disconnect positive line (2) from battery (G1)
4 Install in the reverse order
2010 Smart Fortwo Passion
2009 ACCESSORIES & BODY, CAB Electrical System, Equipment & Instructions - Fortwo (Cabrio)
