Air conditioning Plus
Remove/install
1
Disconnect ground line of
battery (G1)
AR54.10-P-
0003MCC
2 Remove cover (2)
3
Unscrew nut (4) and place
electrical line (3) to one side
4
Detach positive terminal (6) of
electrical line (1) to the battery
(G1)
5
Unclip holder (5) of electrical
line (1) on battery tray
The brackets (5, 8, 14, 15) and the bracket
(arrow A) as well as the protective covers on the
electrical line (1) are present on the new
electrical line (1), when reusing the old electrical
line (1) ensure that it is not damaged.
Risk of death caused by
vehicle slipping or toppling off
of the lifting platform.
Align vehicle between columns of vehicle lift
and position four support plates at vehicle lift
support points specified by vehicle
manufacturer.
AS00.00-Z-
0010-01A
6
Raise vehicle using the vehicle
lift and remove underfloor
paneling
Rechargeable drill / screwdriver
gotis://G_58.0_01.1
7 Release rear drive module
AR01.00-P-
3050MCU
8
Release grommet (7) of
electrical line (1) from battery
recess
Installation: Ensure that grommet (7) is
seated correctly.
9
Mark the position of brackets
(5, 8, 14, 15), the bracket
(arrow A) as well as the bracket
(11) and bracket (arrow B) on
the electrical line (1)
10
Unclip bracket (8) and bracket
(arrow A) of electrical line (1)
on underfloor
11
Unclip electrical line (1) from
holder (9) on brake line (10)
12
Unclip electrical line (1) from
bracket (11) and bracket (arrow
B)
13
Unscrew nut (12) on starter
(M1) and remove electrical line
(1)
14
Unclip bracket (14) of electrical
line (1) on intake manifold
15
Unclip holder (15) of electrical
line (1)
Unscrew nut (13) on alternator
