SCN CODING WITH SDFLASH ONLINE - AR54.21-P-0013-02MCC
The following work instructions describes the procedure for Online SCN coding with "SDflash".
"SDflash" is the product designation of the program for determining the SCN coding and parameterization
data.
"Button F3"
4 Select the control unit to be
flashed in the "systems" menu
and confirm with the "F3
button"
The following control units
can be flashed:
l N3/10 (ME-SFI [ME]
control unit)
l N10/10 (SAM control
unit)
l N15/6 (Sprintshift
control module)
l N47-5(ESP control unit)
5 Select the "Control unit
adaptations" in the selected
menu of the corresponding
control unit and confirm with
the "F3 button"
6 Select the submenu "Program
control unit" in the "Control
unit adaptations" menu and
confirm with the "F3 button"
7 Select the "hard drive menu:
Version Month/ Year
(year/month/day)" and confirm
with the "F3 button"
The information on the
flashing systems appears in
the display.
8 Start the flashing process by
pressing the "F3 button"
Programming lasts about 3
minutes.
9 Select the "online (networked
STAR DIAGNOSIS unit)"
menu or "offline (no
networked STAR
DIAGNOSIS unit)" menu and
start SCN coding by
confirming with the "F3
button"
Only if the SCN coding
command appears in the
display.
We recommend always
performing SCN coding with
SDflash online. Only perform
Offline SCN coding with a
non-networked STAR
DIAGNOSIS.
SCN coding with SDflash
Online
AR54.21-P-0013-
02MCC
Offline SCN coding AR54.21-P-0013-
04MCC
Notes on SCN coding of
control units
AH54.21-P-0004-01X
10 Close STAR DIAGNOSIS
2010 Smart Fortwo Passion
2009 ACCESSORIES & BODY, CAB Electrical System, Equipment & Instructions - Fortwo (Cabrio)
15 октября 2019 г. 19:12:10 Page 33 © 2011 Mitchell Repair Information Company, LLC.
