TEST & ADJUSTMENT VALUES
TEST AND ADJUSTMENT VALUES: SMART: ELECTRICAL SYSTEM, EQUIPMENT AND
INSTRUMENTS - BE54.00-Z-9999CZ
MODEL all
TEST VALUES FOR BATTERY, VOLTAGE SUPPLY - BE54.10-P-1000-01A
All
MODIFICATION NOTES
TEST AND ADJUSTMENT VALUES FOR THE BATTERY
TEST AND ADJUSTMENT VALUES FOR THE BATTERY
Battery MODEL 454.0, 451.391 /491 BA54.10-P-1000-01E
Battery MODEL 451.391/491 BA54.10-P-1000-01H
Control units/base module MODEL 450, 451.334 /380 /480 BA54.21-P-1000-01B
Signaling system MODEL 450.3 BA54.35-P-1000-01B
Wiring harness MODEL 450.3 /4 BA54.18-P-1000-02A
Test values for battery, voltage supply MODEL all BE54.10-P-1000-01A
24.2.06 Cold test current 12 AH
Number Designation 12 AH 30 AH 35 Ah 42 AH
BE54.10-P-
1001-01A
Battery test at
20°C
Acid density
kg/dm
3
- > or =1,24 > or =1,24 -
Maximum
permissible
difference between
individual battery
cells
kg/dm
3
- 0,04 0,04 -
Load current A - 90 100 -
Load time s - 10 10 -
Voltage VV - approx.10 approx.10 -
BE54.10-P-
1002-01A
Cold test
current
as per EN A 170 540 520 340
Number Designation 46 AH
60 Ah
VRLA
60 AH 61 AH
BE54.10-P-
1001-01A
Battery test
at 20°C
Acid density
kg/dm
3
> or
=1,24
- - -
Maximum
permissible
kg/dm
3
0,04 - - -
2010 Smart Fortwo Passion
2009 ACCESSORIES & BODY, CAB Electrical System, Equipment & Instructions - Fortwo (Cabrio)
15 октября 2019 г. 19:12:11 Page 55 © 2011 Mitchell Repair Information Company, LLC.
