TECHNICAL SPECIFICATIONS
VIDEO
Input Interface
(1) DVI-D Female (Single-Link)
Output Interface
(1) DVI-D Female (Single-Link)
Resolution Up to 1920x1200 at 60Hz
DDC / EDID Internal Table can be Re-programmed
Input Equalization Automatic
Input DVI cable length Up to 20 ft.
Output DVI cable length Up to 20 ft.
AUDIO
Signal Type Stereo Audio
Impedance 10K Ohm
Connector 3.5mm Stereo Mini Female
USB
Signaling USB Keyboard and Mouse Only
Input Interface (1) USB Type B
Output Interface (2) USB Type A
OTHER
RS-232 Data up to 115,200 bps
Power Supply PS5VDC4A
Weight 1 lb. TX + RX units
Dimensions 4.5”W X 6”D X 2”H
Fiber Extender
Fiber
730 ft. @ Multimode 62.5μ
1400 ft. @ Multimode 50μ
Fiber-Plug type LC
Operating Temp 32-131°F (0-55 °C)
Storage Temp -4-185 °F (-20-85 °C)
Operating Humidity Up to 95% No Condensation
