Smarter tools MAX-20 - List of Parts

9
transformer is cooled to resume the charging process.
Ⅸ LIST OF PARTS
No.
Specification
Item
QTY
1
GB/T 818-2000 M4×16
Cross rexxessed pan head tapping screw
2
2
GB/T848-2002 4
cushion
4
3
Plastic front panel
1
4
fixed connetion
2
5
50A 85C17-A
ammeter
1
6
K10-2
output fuse
7
KCD-25
power switch
1
8
250w/10A 5x20
Input fuse
9
WS/01-MAX-30-04
Front panel
1
10
K10-2
switch
1
11
GB/T 818-2000 M4×25
Cross rexxessed pan head tapping screw
10
12
QL5010S 50A
rectifier
1
13
GB/T859-87 4
Spring Cushion
2
14
GB/T6170-2000 M4
Hex nut
2
15
GB/T818 M4×10
Cross rexxessed pan head tapping screw
3
16
188×25×3
belt
1
17
140X25MM
Belt buckle
2
18
WS/01-MAX-30-03
Top cover
1
19
ST4.8×13
Cross rexxessed pan head screw
10
20
WS/01-MAX-30-02
Back panel
1
21
Transformer
1
22
GB/T6170-2000 M5
Hex nut
4
23
GB/T859-87 5
Spring gasket
4
24
GB/T848-2002 5
Cushion
4
25
GB/T 818-2000 M5×16
Cross reccessed pan head screw
4
26
Plain washer assemblies
4
27
GB9074.13-88 M4×12
Cross recessed hexagon bolt
2
28
WS/01-MAX-30-01
base
1
29
10A
Accumulator lamp
2
30
3X1.5MMX2.4M
Power cable
31
KCD-25
ON/OFF switch
1
