N
- a - b
F
4a 4b
1
2
-5-
By using the "Allen"
key (N), remove
screw by turning
counter clockwise.
Take the reclining seat (F), lift bottom seat cover
and push the screws through the seat's bottom
holes. Screw tip into the most rear facing hole
and firmly tighten with the Allen key (N).
Step 4
Parts needed to complete this section
