SmartThings Button User Manual

Connect button
TroubleshootingPlacement
The Button can control any connected
devices at a touch of a Button.
Simply place the Button on the table,
desk, or any magnetic mating surface.
The Button can also monitor
temperature.
1.
2.
Hold the “Connect” button with a
paperclip or similar tool for 5
seconds, and release it when the
LED starts blinking red.
Use the SmartThings mobile app to
select “Add device” card and then
follow the on-screen instructions to
complete setup.
If you’re still having trouble connecting
the Button, please visit
Support.SmartThings.com for assistance.
Back Front
LED Light

SmartThings Button Specifications

General

Connectivity	Zigbee
Temperature Range	32°F to 104°F (0°C to 40°C)
Battery Life	Up to 1 year
Power Source	Battery
Compatibility	SmartThings Hub
Functions	Single press, double press
Dimensions	1.6 x 1.6 x 0.6 inches
