SMC Networks TELELIGHT TL90

Figure 4 Upper Elevation
DIAGRAMS/ LABEL EXPLANATIONS
IMPORTANT
FULLY BUNDED UNIT
INSPECT REGULARLY, DRAIN AS REQUIRED
ENSURE ALL PLUGS ARE RE-FITTED.
KEEP DOORS CLOSED WHENEVER PRACTICAL.
BATTERY ACCESS
LA15459
LA03022
RADIATOR FILL
ALLOW TO COOL
DEPRESSURISE
CAREFULLY
LA01945C
FLAMMABLE
Diesel
Fuel
LA15447
6
