Instructions for the user
41
6.2 Cleaning the door glazing
The glass in the door should always be kept thoroughly clean. Use absorbent
kitchen roll; in case of stubborn dirt remove with a damp sponge and an ordinary
detergent.
Cleaning the oven door glazing is made extremely easier as the internal and
middle glass panels can be opened. In this way, each glass panel can be
cleaned both internally and externally. To open the internal glass panel move it
towards the outside (figure 1) working on the points indicated in (figure 2), after
having opened the internal glass panel, the middle glass panel can be opened in
a similar way working on the points indicated in (figure 3).
After cleaning, to put the glass panels back into position, all you have to do is
push them lightly towards the door and insert the pins into their seats.
FIG. 1 FIG. 2 FIG. 3
