Smeg CB2485U - Unit and Cavity Dimensions; Cabinet Door Dimensions

INSTALLATION INSTRUCTIONS
7
Unit and Cavity Dimensions
This built-in appliance is completely enclosed by a kitchen cabinet. The cabinet surrounding the appliance must be
designed in accordance with the specified dimensions and must allow sufficient air circulation to ensure correct
operation of the appliance.
Cabinet Door Dimensions
This appliance requires 2 doors. One for the refrigerator section and one for the freezer section. The custom
doors must be at least 5/8” (16 mm) thick and no more than 3/4” (19mm) thick. The space between the top
and bottom doors must be at least 1/8” (3mm), the same as the appliance door space. Similar space is
required between the top door and the cabinet door above the appliance (if applicable) – 1/8” (3mm).
Spacing between the cabinet doors and the existing cabinets should comply with the existing kitchen
cabinets, typically 1/8” (3mm) should be allowed.The cabinet doors must follow the recommended weight
requirements –
Fridge compartment door 37.5 lbs (17 kg)
Freezer compartment door 26.5 lbs (12 kg)
Detailed specs for custom doors for appliance: Specs provided for the width of the appliance doors in the
diagram. Detail for designers/planners.
Fridge 38
13
/
16
” ( 988 mm)
Freezer 25” (640 mm)
Unit Cavity
Width
21
1
/
4”
540mm
Width
Min. 22
1
/
8”
Min. 560mm
Height
69
41
/
64”
1769mm
Height
69
23
/65” – 69
27
/
32”
1771 – 1774mm
Depth
21
21
/
32”
550mm
Depth
Min. 22
3
/
64”
Min 560mm
