Instructions for the installer
99
11.7 Wall mounting instructions (some markets only)
1 Fasten a hook bolt (not supplied) into the wall at
a height (h) of 800 mm from the floor.
The installer must provide the hook bolt when installing the appliance.
2 Attach the snap hook to the chain.
3 Attach the end of the chain to the hook bolt
fastened in the wall.
4 Finally, connect the snap hook to the appropriate
hole on the back of the appliance.
