Instructions for the user
4. PRODUCT DESCRIPTION
4.1 CVB 20
1 Freezing area for deep-frozen foods and fresh
foods; compartments with doors.
2 Control unit.
3 Area for keeping fresh foods; pull-out drawers.
4 Defrosted water outlet.
5 Serial number plate (located inside the
appliance).
6 Eutectic salt container (if provided) and/or ice
cube container.
4.2 Controls
7 Button for turning the appliance on and off, setting the temperature and setting the “rapid freeze”
function.
8 High temperature green indicator light (less cold).
9 Medium temperature green indicator light (cold).
10 Low temperature green indicator light (colder).
11 Temperature alarm red warning light.
Note:
all green lights lit indicate that the rapid freeze function is active
