Mounting Instructions
11
Mounting Dimensions and Required Air
Circulation
The rear wall of the appliance is getting warm during the operation
of the appliance (and water is evaporating from the drain pan on
the compressor). You must therefore provide for adequate air
circulation on the rear of the appliance.
• At the base of the kitchen unit intended for building in the
integrated appliance, there should be at least 200 cm² free
space, for adequate air circulation.
• On the upper part of the appliance the air is coming out, so try
not to cover the opening for the outflow air.
A (mm) B (mm)
575 575-580
875 875-880
1025 1025-1030
1225 1225-1230
