11
AIR OUTLET IN THE RECYCLING MODE
• Open the metal grid and make sure that the conver-
sion knob is in the recycling position.
• Place the charcoal filter. The charcoal filter is not
supplied together with the hood. (Hoods with two
motors needs to be equipped with two charcoal fil-
ters).
INSTRUCTIONS FOR OPENING AND REMOVING THE
METAL GRILLE PANEL
• To open the grille, pull the facia panel out into the
operating position.
• Press inwardly on the two slide catch fastners, lo-
cated at each side of the grille near the facia panel,
while pulling the grille panel onwards. The grille
may then pivot down.
• To remove the grille, release the right hand hinge pin
from the slot along the casing and the grille can be
removed.
ELECTRICAL CONNECTION
• Connect the hood to the mains through a two-pole switch having a contact gap of at least 3
mm..
