Instructions for use
By pushing buttons shown in the figure 1, you
will be able to control the functions of the
extractor
Two achieve better extraction, we recommend
switching on the extractor a few minutes
before starting to cook (3 - 5 minutes) so that
the air flow is continuous and stable when
extracting the fumes.
Likewise, keep the extractor switched on for a
few minutes when cooking is complete to
allow all fumes and odours to be expelled.
Cleaning and maintenance
Before carrying out any cleaning or
maintenance activities, ensure that the
extractor is disconnected from the mains.
To carry out cleaning and maintenance, follow
the Safety Instructions.
Filter cleaning
To remove the filters from their locations
release the anchoring points. Clean the filter,
either by putting it in the dishwasher (see
notes) or leaving it standing in hot water to
simplify the removal of grease or, if wished, by
means of special sprays (protecting the non
metallic parts). Once clean, leave it to dry.
Notes: cleaning in the dishwasher with
aggressive detergents may darken the surface
of metallic parts, without this affecting its gas
retaining properties.
N.B. The filter must be cleaned at least once a
month depending on how often the extractor is
used. It must be remembered that grease
accumulates in the extractor when cooking,
whether it is switched on or not.
Cleaning of the extractor body
The use of warm (40ºC approx.) soapy water
is recommended. A cloth moistened in this
water is used for cleaning the extractor, paying
special attention to the grids. Afterwards, dry it
using a lint-free cloth.
Note:
* Never use metallic scouring pads or abrasive
products that could damage the surface.
* Do not use scrapers with metallic surfaces
such as knives, scissors etc.
Active charcoal filter
* To install the charcoal filter, the motor
anchorage is made to coincide with the anchor
points of the activated charcoal filter and turn it
clockwise.
* The carbon filter lasts from three to six months
depending on the particular conditions of use.
* The activated carbon filter can neither be
washed nor regenerated. Once it is exhausted,
it must be changed.
* To replace exhausted filters with new ones,
withdraw the old one in the reverse order to
that of installation.
Changing Bulbs
* It is important that the mains are
disconnected, and ensure the bulbs that are to
be replaced are not hot.
* Remove the light lens to expose the
extractable lamps.
* The maximum bulbs power is 40W.
Technical Information (Fig.3)
Dimensions: Width = 600 mm
Depth = 280mm
Height = 181mm
Electrical characteristics:
REFER TO RATING PLATE
Speed Vitesse Velocidad
