WORKTOP ILLUMINATION
If a lamp fails to function at any time, open the metal
grille panel and check that the lamp is fully screwed
into the holder.
When changing the lamp, an identical replacement
must be fitted to ensure a safe working of the hood.
Lamp Power (W) Socket Voltage (V) Dimension (mm) ILCOS Code
4
E14
220-240
107 x 37
DRBB/F-4-220-240-E14-35/100
5
GU10
230
52 x 50
DRPAR-5/840-220/240-GU10-35/36
DRPAR-5/830-220/240-GU10-35/36
