Smeg LBS106F - Installation; Removing Packaging Reinforcement; Opening the Transportation Locks; Connecting to the Drain

3 - EN
2 Installation
Removing packaging reinforcement
Tiltthemachinetoremovethepackaging
reinforcement.Removethepackaging
reinforcementbypullingtheribbon.
Opening the transportation locks
A
Transportationsafetyboltsmustberemoved
beforeoperatingthewashingmachine!
Otherwise,themachinewillbedamaged!
1. Loosenalltheboltswithaspanneruntilthey
rotatefreely(“C”)
2. Removetransportationsafetyboltsbyturning
themgently.
3. Fitthecovers(suppliedinthebagwiththe
OperationManual)intotheholesontherear
panel.(“P”)
 
C
Keepthetransportationsafetyboltsinasafe
placetoreusewhenthewashingmachine
needstobemovedagaininthefuture.
C
Nevermovetheappliancewithoutthe
transportationsafetyboltsproperlyfixedin
place!
Adjusting the feet
A
Donotuseanytoolstoloosenthelocknuts.
Otherwise,theycanbedamaged.
1. Manually(byhand)loosenthelocknutsonthe
feet.
2. Adjustthemuntilthemachinestandsleveland
firmly.
3. Important:Tightenalllocknutsupagain.
Connecting to the water supply.
Important:
• Thewatersupplypressurerequiredtorunthe
machinemustbe1-10bar(0,1–1MPa).
• Connectthespecialhosessuppliedwiththe
machinetothewaterintakevalvesonthe
machine.
• Ifyouaregoingtouseyourdoublewater-inlet
machineasasingle(cold)water-inletunit,you
mustinstallthestopper*,suppliedwithyour
machinetothehotwatervalve.
• Ifyouwanttousebothwaterinletsofthe
product,youcanconnectthehotwaterhose
afterremovingthestopperandgasketgroup
fromthehotwatervalve.
*Appliesfortheproductssuppliedwithablind
stoppergroup.
• Modelswithasinglewaterinletshouldnotbe
connectedtothehotwatertap.
Whenreturningtheappliancetoitsplaceafter
maintenanceorcleaning,careshouldbetakennot
tofold,squeezeorblockthehoses.
Connecting to the drain
Thewaterdischargehosecanbeattachedtothe
edgeofawashbasinorbathtub.Thedrainhose
shouldbefirmlyfittedintothedrainastonotget
outofitshousing.
Important:
• Theendofthedrainhosemustbedirectly
connectedtothewastewaterdrainortothe
washbasin.
• Thehoseshouldbeattachedtoaheightofat
least40cm,and100cmatmost.
• Incasethehoseiselevatedafterlayingiton
thefloorlevelorclosetotheground(lessthan
40cmabovetheground),waterdischarge
becomesmoredifficultandthelaundrymay
comeoutwet.
• Thehoseshouldbepushedintothedrainage
formorethan15cm.Ifitistoolongyoumay
haveitshortened.
• Themaximumlengthofthecombinedhoses
mustnotbelongerthan3.2m.
Electrical connection
Connectthemachinetoanearthedoutlet
protectedbyafuseofsuitablecapacity.
Important:
• Connectionshouldcomplywithnational
regulations.
• Thevoltageandtheallowedfuseprotection
arespecifiedinthesection“Technical
Specifications”.
