User instructions
10
3. Description of the controls
3.1 Front panel
All the dishwasher controls are grouped on the front panel. Programming
and option selection are only possible with the door closed.
1 ON/OFF BUTTON AND WARNING LIGHT
2 OPTION SELECTION BUTTONS AND WARNING LIGHTS
3 “CHILD LOCK” ACTIVATION BUTTONS
4 NO RINSE AID LIGHT (some models only)
5
WATER HARDNESS ADJUSTMENT ON INDICATOR LIGHT/
SALT WARNIN LIGHT (on some models only)
6 START/PAUSE BUTTON
7 PROGRAM SELECTION BUTTON
8 PROGRAM LIGHTS
9 HANDLE TO OPEN THE DOOR
N.B.: symbols and styling are guideline and may vary depending on
the model or version of the dishwasher purchased.
