Smeg SA550-2X90 - Page 2

SA550-2X90
smeg 90cm deluxe slim jim telescopic rangehood
ID310812
Code SA550-2X90
WARNING: technical specifications and product sizes can be varied by the manufacturer, without notice.
Cutouts for appliances should only be by physical product measurements. The above information is
indicative only.
packaged dimensions 400mm x 900mm x 300mm = 0.102m³
gross weight
16.5kg
net weight 14.5kg
capacity 800m
3
/hr net
air extraction duct or recirculate
NB: 150mm diameter (6”) ducting required — not
supplied
electrical supply 240 volt, 50 Hz
electrical connection 1.15 metre connected power cord with 3-pin plug
suitable for standard 10 amp GPO
wattage (motor) 250 watt centrifugal, twin impellors, double air
uptake
maximum current 1.17 amp
lights two 20-watt halogen
supplied • brackets, screws, instructions for installation,
operation and maintenance
• rear spacer for optional tment
• non-return buttery valve for optional tment
• 2 x 4-ply stainless steel/aluminium grease lters
optional pair activated charcoal filters for optional use when
recirculation, part number 08999801 for pair
598 - 898
498
260
40
50
280
85
150ø
30
120
connected
power cord
1.15 metre
SIDE ELEVATION
FRONT ELEVATION
optional tment of
charcoal lters for
recirculation installation
o
shelf for
mounting
bracket
55
transformer
retractable front rail


fixed spigot
150
o
25
60
40
30
898
SPEED 1 2 3 4
net air capacity m
3
/hr 330 500 660 800
pressure mm H20 34 43 46 48
wattage 135 170 210 250
noise dBA 41 48 54 58
85
150
fixed spigot
12
60
shelf for
mounting
bracket
transformer
 
280
120
34
40
30
260
70
plastic ller
piece for optional
tment
max depth 70mm
798
