Installation
41
EN
B - Class 2 subclass 1
(Built-in appliance)
C - Class 2 subclass 1
(Built-in appliance)
Assembling the skirt
The skirt must always be positioned and
secured correctly on the appliance.
1. Loosen the 4 screws (A) on the back of
the hob (2 for each side) using a
screwdriver.
2. Place the skirt on the worktop.
3. Align the slots of the skirt (B) with the
screws (A).
4. Secure the skirt to the worktop by
tightening the 4 screws previously
loosened.
The appliance must be installed by
a qualified technician and
according to the regulations in
force.
The skirt provided is an integral
part of the product; it must be
fastened to the appliance prior to
installation.
