Installation
85
EN
B - Class 2 subclass 1
(Built-in appliance)
C - Class 2 subclass 1
(Built-in appliance)
Assembling the skirt
The skirt must always be positioned and
secured correctly on the appliance.
1. Loosen the 6 screws on the back of the
top (A) and unscrew the 2 screws (B) on
the side part of the skirt.
2. Place the skirt on the top. Align the 6
bottom slots of the skirt with the 6 screws
on the back of the top that were
previously loosened.
3. Tighten the 6 screws on the back of the
hob (A) and tighten the 2 screws under
the top (B) to secure the skirt.
The appliance must be installed by
a qualified technician and
according to the regulations in
force.
The skirt provided is an integral
part of the product; it must be
fastened to the appliance prior to
installation.
