Installation
73
EN
B - Class 2 subclass 1
(Built-in appliance)
C - Class 2 subclass 1
(Built-in appliance)
Assembling the backguard
The backguard must always be positioned
and secured correctly on the appliance.
1. Loosen the 6 screws on the back of the
top (A) and unscrew the 2 screws (B) on
the side part of the backguard.
2. Place the backguard on the top. Align
the 6 bottom slots of the backguard with
the 6 screws on the back of the top that
were previously loosened.
3. Tighten the 6 screws on the back of the
hob (A) and tighten the 2 screws under
the top (B) to secure the backguard.
The appliance must be installed by
a qualified technician and
according to the regulations in
force.
The backguard provided is an
integral part of the product; it must
be fastened to the appliance prior
to installation.
