GB
11
Description of the
appliance
Overall view
The instructions contained in this manual are applicable to different model refrigerators. The diagrams may not
directly represent the appliance purchased.
TEMPERATURE
CONTROL Knob
GREEN indicator light
This is illuminated when the appliance is connected to
the electricity mains (press the ON/OFF switch so it is
in the - position).
RED Light
This light goes on when the temperature inside the
appliance is not sufficient to preserve foodstuffs.
YELLOW indicator light
This is illuminated when the TEMPERATURE
ADJUSTMENT knob is in the Super position.
TEMPERATURE ADJUSTMENT knob
This automatically adjusts the temperature inside the
appliance.
Increasingly cold temperatures may be selected by
moving the knob from position 1 to position 4.
The Super position is used to freeze fresh food.
0
4
1
2
3
!
ON/OFF switch
RED indicator Light YELLOW indicator Light
GREEN indicator Light
0
4
1
2
3
!
FREEZER and
STORAGE
compartment
STORAGE
compartment
