smev FO200FT - Connecting to Gas Supply

INSTALLATION
USE
MAINTENANCE
CATEGORY AND COUNTRY OF DESTINATION
I3B/P(30)
AT BE DK FI DE GB NL NO SE CH SI
I3+ (28-30/37)
BE FR IE IT ES CH GB PT SI
GAS PRESSURE
30 mbar Butane (G30)
30 mbar Propane (G31)
28-30 mbar Butane (G30)
37 mbar Propane (G31)
MODEL TOTAL NOMINAL THERMAL
CAPACITY
AIR VOLUME REQUIRED FOR
COMBUSTION
FO200FT - FO200FTFE
FO290TD - FO290TS
FO390TD - FO390TS - OF300F
OF300FAL - OF300FT - OF300FTL
555 - 565 - FO211FGT
FO291TD - FO291TS
FO391TD - FO391TS
OF311FG - OF311FGT
1,6 KW - 116 gr/h
3,2 m
3
/h
1,2 KW - 87 gr/h
2,4 m
3
/h
WHEN INSTALLING AND CONNECTING THE APPLIANCE TO THE GAS SUPPLY,
ENSURE THAT THE GAS SUPPLY HOSE IS NOT TWISTED, STRETCHED OR
SUBJECTED TO ANY FORM OF STRAIN WHICH COULD CREATE A HAZARD.
The gas supply pipe connected to the appliance must be a rigid metal pipe with sealed fittings. It is possible to fit a
flexible hose, however, in this case the following conditions must be respected:
14
ENGLISH
This appliance is designed for running off the following types of gas at the corresponding operating pressures. The gas
category (or categories) of the appliance is given on the specifications label affixed to the appliance.
CONNECTING TO GAS SUPPLY
CHECK THESE SPECIFICATIONS BEFORE CONNECTING THE APPLIANCE TO THE
GAS CYLINDER /BOTTLE. THE PRESSURE REGULATORS CONNECTED BETWEEN
THE GAS CYLINDER AND APPLIANCE MUST CONFORM WITH THE CATEGORIES
GIVEN IN THE TABLE BELOW.
1 Mount the flue attachment (K) and secure in place with the 2 fixture screws provided as illustrated in FIG. 3 – PG.
126 and then proceed with connecting the ducting to the flue.
2 The roof mounted flue must be positioned vertically with a maximum inclination of 15°. Drill a 60mm
∅ hole in
the roof of the vehicle in proximity of the oven. To avoid damaging or denting the roof when installing the flue and
to ensure sealing if required mount a 1mm thickness metal plate to the wall with the hole.
3 Install the flue and from the inside of the vehicle secure in place with the nut. To guarantee the roof is sealed and
does not leak, after the oven has been on for several hours re-tightened the flue fixture nut.
4 Mount and install the ducting as illustrated in FIG. 4 – PG.127. Feed the ducting into the flue until it stops and secure
in place with a self-tapping screw.
5 Using ties secure the ducting (∅ 55mm) and the protective tubing (∅ 65mm) for their entire lengths to the walls.
