6
Introduction
SPECIFICATIONS
WEIGHTS AND DIMENSIONS
Length 112" (285 cm)
Width 70" (178 cm)
Width With Boom Open 180" (457 cm)
Height 48" (122 cm)
Wheel Base 53" (135 cm)
Weight Empty 1200 lbs (544 kg)
Weight Full 2200 lbs (998 kg)
SOUND LEVEL (DB)
At ear level 88 dB
At 3 ft (0.914 m) 84 dB
At 30 ft (9.14 m) 72 dB
ENGINE
Make Kohler
Model# Command CH25S
Type / Spec# PA 68673
Horsepower 25 hp (18 kW)
Fuel Unleaded 87 Octane Gasoline Minimum
Cooling System Air Cooled
Lubrication System Full Pressure
Alternator 25 amp
WHEELS & TIRE Front: Two 20 x 10.00 x 10 NHS Multi-Rib; 20 psi (1.4 bar)
Rear: Two 24 x 12.00 x 12 NHS Multi-Trac; 20 psi (1.4 bar)
SPEED
Forward Speed 0-8 m.p.h. (0-12.8 kph)
Reverse Speed 0-3 m.p.h. (0-4.8 kph)
BATTERY Automotive type 24F - 12 volt
BCI Group Size 24
Cold Cranking Amps 575 minimum
Ground Terminal Polarity Negative (-)
Maximum Length 10.25" (26 cm)
Maximum Width 6.88" (17 cm)
Maximum Height 10" (25 cm)
FLUID CAPACITY
Crankcase Oil See Engine Manual
Fuel 5 gallon (19 liters)
Hydraulic Fluid 5 gallon (19 liters)
Grade of Hydraulic Fluid SAE 10W-40 API Service SJ or higher Motor Oil
OPTIONAL EQUIPMENT
10-108 Speedometer Kit 10-260 203 Spray System (1002)
10-106 Fresh Water Tank 10-102 Manual Spray System (1004)
10-103 Electric Actuator Lift Kit 10-101 834 Spray System (1006)
10-297 Hydraulic Actuator Lift Kit 10-110 440 Spray System (1008)
10-105 Foam Marker 10-270 3-Way Manual System (1010)
10-160 15' Stainless Steel Boom - manual 33-216 Battery Automotive Type 24F-12 volt
10-301 15' Terrain Following Boom
10-107 Hose Reel Mounting Kit
16-906 Hose Reel 12 volt electric rewind 200' (61 m) capacity (to be used with 10-107)
16-129 Hose Reel 200'(61 m) capacity (to be used with 10-107)
