Floor Latch
Floor latch
Step 1: Open tent fully. Locate hinge latch in the center of the tent on the main hinge. Then
swing latch arm over the latch post. You many have to pull down on the tent floor to get latch
arm and post to line up correctly. Fig 10-12.
Step 2: Release floor latch before folding tent into the closed position.
Note: Periodically lube latch with BreakFree CLP.
open
closed
Fig 10
Fig 12
Fig 11
closed
13
Periodically check torque
of all hardware.
