Smittybilt Overlander Tent - Veranda Guy Rope Attachment

WWW.SMITTYBILT.COM
Fig 7 shows the
orientation of the
support poles and
main hoop without
tent skin.
Fig 7
Fig 8
Step 4: Attach guy ropes to veranda and secure with stakes. Fig 9 & 10.
Veranda Support
XL models
17
Periodically check torque
of all hardware.
