WWW.SMITTYBILT.COM
Installation Instructions
Scout Trailer Kit
Part#87400/87400-01
Fig 18 Fig 19 Fig 20
Fig 18 shows unfinished strap cut. You may cut the strap at an
angle to aid in threading it into the ratchet mechanism, or you
may cut it straight across. Fig 19 shows sealing the end of the
strap with a flame. Fig 20 shows finished sealed strap. When
tightening ratchet always make sure to lock ratchet mechanism
in the fully closed lock position. Fig 21
Fig 21
22
