WWW.SMITTYBILT.COM
Installation Instructions
Scout Trailer Kit
Part#87400/87400-01
33. Lube all zerk fittings with a lithium based grease. Zerk fittings are found on the trailing arms
where they mount to the trailer frame. Each trailing arm has two zerk fittings. Always clean zerk
fitting before attaching grease gun to fitting. White lithium grease is recommended. DO NOT
use petroleum based grease as this will damage the bushings. Stay away from spray lube. When
greasing bushings, pump in enough grease to push out old grease, keep filling till all the
discolored old grease is removed. Fig 38.
34. Mount tail lights to fenders and connect quick connect fitting. Mount license plate on the driver
side fender if a license plate is used. Fig 39.
35. Turn to page 51 for alignment instructions.
36. Apply wicking grade loc-tite/threadlocker (green) to all fasteners.
X4
Fig 38
Fig 39
31
