Installation Instructions
Scout Trailer Kit
Part#87400/87400-01
• Keep lock , T-handle, and locking arm
clean and lubed.
Tongue Box BOM List
Component Name Qty
Secondary Component
Name Qty
Work piece
Box lid
1
Box body
1
Large washer
4
Standard Component
Hexagon head
bolt M10*80
4
M10 flat
washer
4
M10 lock
washer
4
M10 nut
4
Accessories
Air stay
1
Hardware
M8 nut
2
M8 lock washer
2
M8 flat washer
2
T-
lock 1
Hardware
M5*16 stainless steel
bolt
4
M5 flat washer
4
M5 lock washer
4
M5 nut
4
Hinge
3
Hardware
M4*10 stainless steel
bolt
18
M4 flat washer
18
M4 lock washer
18
M4 nut
18
Seal
2.3m
