Smittybilt Scout - Page 36

WWW.SMITTYBILT.COM
Installation Instructions
Scout Trailer Kit
Part#87400/87400-01
Torque:
M14 bolts:120 ft/lb
M16 bolts:165 ft/lb
36
Draw Bar BOM
List
Component
Name
Qt
y
Secondary
Component
Name
Qt
y
Work piece
Draw bar
1
Tire rack base plate
1
Hand brake plate
1
Hardware
M5*10 bolt
4
M5 flat washer
8
M5 lock washer
4
M5 nut
4
Reveiver hitch tube
1
Hardware
Pin
φ15*75
1
Washer
φ15
1
Cotter pin
φ3
1
Standard
Component
M16*45 hexagon
head bolt
2
M16*110 hexagon
head bolt
1
M16 Flat washer
6
M16 lock washer
3
M16 nut
3
M14*85 hexagon
head bolt
4
M14 flat washer
8
M14 lock washer
4
M14 nut
4
Accessories
Hand brake
1
Hardware
M12*40 hexagon
head bolt
2
M12 Flat washer
4
M12 lock washer
2
M12 nut
2
Safety chain (920mm)
2
Hardware
D ring
4
Reveiver hitch
1
Hardware
M12*85 hex bolt
2
M12 flat washer
4
M12 nut
2
M12 lock washer
M12X20 bolt
1
Jackey wheel
1
Hardware
M12*35 hexagon
head bolt
4
M12 Flat washer
8
M12 lock washer
4
M12 nut
4
Clearance Lamp
2
Hardware
M4*16 self
-tapping
screw
4
