Installation Instructions
Scout Trailer Kit
Part#87400/87400-01
Cabin&Frame BOM List
Component Name Qty
Secondary
Component
Name Qty
Work piece
Cabin body 1
Reinforce rib 2 Hardware
M10*20 bolt
6
Accessories
Eyebolt 11
Kitchen door
seal
2180mm
Generator door
seal
2180mm
back door seal
3580mm
M12*20 Jack
bracket bolt
2
M12*20 bolt 1
60mm tube bolt
1
