Installation Instructions
Scout Trailer Kit
Part#87400/87400-01
Left Suspension System BOM List
Component Name Qty
Secondary
Component
Name
Qty
Work piece
Trailing arm
-left 1 Hardware
M6*140 bolt
2
M16flat washer
2
M16 lock washer
2
M16 nut
2
Accessories
coil spring
1
coil seat
2
Bump stop
1 Hardware
M10*30 bolts
1
Bushing
4
Liner pipe
2
Shock
2 Hardware
M16*80 bolt
4
M16 flat washer
8
M16 lock washer
4
M16 nut
4
Limit strap
1 Hardware
M10*90 bolt
2
M10 washer
4
M10 nut
2
M10 lock washer
2
Brake system
1 Hardware
M16*60 bolt
4
M16 flat washer
8
M16 lock washer
4
M16 nut
4
Right Suspension System BOM List
Component Name Qty
Secondary
Component
Name
Qty
Work piece
Trailing arm
-
right
1 Hardware
M6*140 bolt
2
M16flat washer
2
M16 lock washer
2
M16 nut
2
Accessories
coil spring
1
coil seat
2
Bump stop
1 Hardware
M10*30 bolts
1
Bushing
4
Liner pipe
2
Shock
2 Hardware
M16*80 bolt
4
M16 flat washer
8
M16 lock washer
4
M16 nut
4
Limit strap
1 Hardware
M10*90 bolt
2
M10 washer
4
M10 nut
2
M10 lock washer
2
Brake system
1 Hardware
M16*60 bolt
4
M16 flat washer
8
M16 lock washer
4
M16 nut
4
