Smittybilt Scout - Page 45

WWW.SMITTYBILT.COM
Installation Instructions
Scout Trailer Kit
Part#87400/87400-01
Tent Rack BOM List
Component Name Qty
Secondary
Componen
t
Name Qty
Work piece
Rack
-1 2
Hardware
φ10*65
Pin 4
φ10
flat
washer
4
cotter pin
φ3 4
U Rack
4
Accessories
M10 Knob
4
φ10*55
Pin 4
cotter pin
φ3 4
φ10
Washer 4
U-rack for
tent
mounting
