Installation Instructions
Scout Trailer Kit
Part#87400/87400-01
Left Fender BOM List
Component
Name Qty
Secondary
Component
Name Qty
Work piece
left fender
1 Hardware
M10*25 hexagon
head bolt
6
M10 Flat washer
12
M10 lock washer
6
M10 nut
6
Tail light
bracket
1 Hardware
M6*16 bolt
4
M6 flat washer
8
M6 lock washer
4
M6 nut
4
Accessories
Tail light
1 Hardware
M6 nut
2
M6 flat washer
2
Right Fender BOM List
Component
Name Qty
Secondary
Component
Name Qty
Work piece
Right fender
1 Hardware
M10*25 hexagon
head bolt
6
M10 Flat washer
12
M10 lock washer
6
M10 nut
6
Tail light
bracket
1 Hardware
M6*16 bolt
4
M6 flat washer
8
M6 lock washer
4
M6 nut
4
Accessories
Tail light
1 Hardware
M6 nut
2
M6 flat washer
2
