Smittybilt Scout - Page 47

WWW.SMITTYBILT.COM
Installation Instructions
Scout Trailer Kit
Part#87400/87400-01
Left Jack BOM List (shown)
Component
Name Qty
Secondary
Component
Name
Qty
Work piece
Jack
bracket
1
Hardware
φ12*65
Pin 1
φ12
Flat washer 1
Cotter pin
φ3 1
Accessories
Jack
1
Hardware
φ12*65
Pin 1
1
φ12
Flat washer 1
1
Cotter pin
φ3 1
Right Jack BOM List
Component
Name Qty
Secondary
Component
Name
Qty
Work piece
Jack
bracket
1
Hardware
φ12*65
Pin 1
φ12
Flat washer 1
Cotter pin
φ3 1
Accessories
Jack
1
Hardware
φ12*65
Pin 1
1
φ12
Flat washer 1
1
Cotter pin
φ3 1
47
